NFC Sticker Circus 22 mm - NTAG213 - 180 Byte - transparent
€2.96 *
€2.96*
€2.07*
€1.00*
€0.77*
€0.70*
€0.52*
€0.40*
€0.39*
€0.26*
€0.25*
€0.23*
€0.21*
€0.20*
The transparent sticker made of PET can be easily applied to all smooth surfaces and is particularly suitable for marketing campaigns and identification due to its robustness.
Short description
- PET material, flexible, self-adhesive
- not suitable for metallic/conductive surfaces
- 22 mm diameter
- Indoor use, conditionally also outdoor use
- Ambient temperature from -25 to +70 degrees
- NXP NTAG213 (NTAG213) - 180 Byte (NDEF: 137 Byte)
Product description
NFC product
NFC chip
- Total capacity: 180 bytes
- Free memory: 144 bytes
- Usable memory NDEF: 137 byte
| NFC Product | |
| Adhesive layer: | Yes |
|---|---|
| Antenna: | Aluminium |
| Antenna format: | 20 mm |
| Available colours: | transparent |
| Chip standards / ISO Norm: | ISO 14 443-2 A, ISO 14 443-3 A |
| Detail colour: | transparent |
| Dimensions: | 22 mm Ø |
| Material: | PET |
| Material thickness: | 0,11 mm (T) |
| Operating temperature: | Min -25°C - Max +70°C |
| Product form: | round |
| Storage temperature: | Min -55°C - Max +125°C |
| Type: | Sticker |
| Weight: | 1 g |
| Delivery options | |
| Number of tags per roll: | 5000 pieces |
|---|---|
| Roller core diameter: | 76 mm |
| NFC Chip | |
| Chip: | NXP NTAG213 |
| Chip standards / ISO Norm: | ISO 14 443-2 A, ISO 14 443-3 A |
| Frequency: | 13.56 MHz |
| Memory: | 180 Byte (free: 144 Byte, NDEF: 137 Byte) |
| NFC Forum Type: | NFC Forum type 2 |
| Functions | |
| Compatibility: | to NFC-enabled smartphones: 100% |
| Data retention: | 10 years |
| Data transfer rates: | 106 kbit/s |
| Number of write operations: | 100.000 times |
Login
NFC tags with NTAG chipset are compatible with all NFC-enabled smartphones. The NFC chips are delivered without content (empty). The use of NFC tags with a chipset of the NXP NTAG series is simple, but depends on the operating system used. The following links aim to give a quick start into that topic.
Android
Android smartphones with NFC require additional apps to write to NFC tags. We have compiled typical use cases in our NFC for Android How2 collection.
iOS
NFC tags can be used in iOS with the integrated app "Shortcuts". For other use cases, we recommend an additional app, for example our free iOS app NFC21 Tools. In our NFC for iOS How2 collection, we have included several use cases for writing NFC tags with iOS devices.
Windows
In order to be able to use NFC tags under Windows, both suitable hardware (NFC USB reader/writer) and suitable software are required. In our How2 collection we show how to use the NFC tags with the appropriate NFC hardware and software (e.g. our free software NFC21-Tools).
