NFC Sticker BullsEye On-Metal - 38 mm - NTAG213 - 180 Byte - white

Product number: 68774

€3.49 *

Prices incl. VAT plus shipping costs

Quantity

Unit price

From 1

€3.49*

From 2

€2.69*

-22.9 %

From 5

€1.90*

-45.6 %

From 10

€1.65*

-52.7 %

From 20

€1.58*

-54.7 %

From 50

€1.39*

-60.2 %

From 100

€1.30*

-62.8 %

From 250

€1.25*

-64.2 %

From 500

€1.23*

-64.8 %

From 1000

€1.13*

-67.6 %

From 2000

€1.02*

-70.8 %

From 5000

€1.01*

-71.1 %

2559 available. Contact us if you are interested in a higher quantity.

Product information "NFC Sticker BullsEye - On-Metal - 38 mm - NTAG213 - 180 Byte - white"

The white sticker made of PET can be easily applied to all smooth and metallic surfaces and is particularly suitable for marketing campaigns and identification due to its robustness.

Short description

PET material, flexible, self-adhesive
suitable for metallic/conductive surfaces
38 mm diameter
Place of use indoor, conditionally also outdoor
Ambient temperature -25 to +70 degrees
NXP NTAG213 (NTAG213) - 180 Byte (NDEF: 137 Byte)

Product description

NFC product

The surface material of the white NFC sticker is made of PET. The material is therefore conditionally waterproof, so that the sticker can withstand moisture even in moderation. The sticker has a diameter of 38 mm and a material thickness of 0.35 mm. The antenna is visible from the outside, because the sticker is transparent.

The chipset of the sticker is compatible with all current NFC-enabled smartphones.

NFC chip

The self-adhesive PET sticker is equipped with the original NXP NTAG213 and offers a cost-effective entry into the NTAG21x series. The NXP NTAG21x series impresses with the greatest possible compatibility, good performance and intelligent additional functions. The NTAG213 has a total capacity of 180 bytes (free memory 144 bytes), thereof usable memory in the NDEF 137 bytes. Each individual chip has a unique serial number (UID) consisting of 7 bytes (alphanumeric, 14 characters). The NFC chip can be written up to 100,000 times and has a data retention of 10 years. The NTAG213 has the UID ASCII Mirror feature, which allows the tag's UID to be appended to the NDEF message, as well as an integrated NFC counter that automatically increments during readout. Both features are not enabled by default. The NTAG213 is compatible with all NFC-enabled smartphones, NFC21 tools and all ISO14443 terminals.

Total capacity: 180 Byte
Free memory: 144 Byte
Usable memory NDEF: 137 Byte

NFC Product
Adhesive layer:	Yes
Antenna:	Aluminium
Available colours:	white
Chip standards / ISO Norm:	ISO 14 443-2 A, ISO 14 443-3 A
Detail colour:	white
Dimensions:	38 mm Ø
Material:	PET
Material thickness:	0,35 mm
On-metal:	on metal
Operating temperature:	Min -25°C - Max +70°C
Storage temperature:	Min -55°C - Max +125°C
Type:	Sticker

There may be differences in weight, dimensions and material thickness due to the manufacturing process.

NFC Chip
Chip:	NXP NTAG213
Chip standards / ISO Norm:	ISO 14 443-2 A, ISO 14 443-3 A
Memory:	180 Byte (free: 144 Byte, NDEF: 137 Byte)
NFC Forum Type:	NFC Forum type 2
Functions
Compatibility:	to NFC-enabled smartphones: 100%
Data retention:	10 years
Data transfer rates:	106 kbit/s

0 of 0 reviews

Leave a review!

Share your experiences with other customers.

Login

Your email address

Your password

No reviews found. Share your insights with others.

PDF-Datasheet

NFC tags with NTAG chipset are compatible with all NFC-enabled smartphones. The NFC chips are delivered without content (empty). The use of NFC tags with a chipset of the NXP NTAG series is simple, but depends on the operating system used. The following links aim to give a quick start into that topic.

Android

Android smartphones with NFC require additional apps to write to NFC tags. We have compiled typical use cases in our NFC for Android How2 collection.

iOS

NFC tags can be used in iOS with the integrated app "Shortcuts". For other use cases, we recommend an additional app, for example our free iOS app NFC21 Tools. In our NFC for iOS How2 collection, we have included several use cases for writing NFC tags with iOS devices.

Windows

In order to be able to use NFC tags under Windows, both suitable hardware (NFC USB reader/writer) and suitable software are required. In our How2 collection we show how to use the NFC tags with the appropriate NFC hardware and software (e.g. our free software NFC21-Tools).
