Product information "NFC Starter Kit Maxi - 21 pieces"
The NFC Starter Kit Maxi offers a wide range of different NFC products. It contains items from all our product categories and three different chip sets. Thus, it offers the ideal start to get to know the comprehensive possibilities of NFC technology.
Brief description
- PET (sticker, magnet), PVC (card), epoxy (tag)
- partly suitable for metallic / conductive surfaces
- Indoor use, limited outdoor use
- ambient temperature from -25 to +70 degrees
- NXP NTAG213 (NTAG213), NXP NTAG215 (NTAG215), NXP NTAG 216 (NTAG216)
Product description
NFC productThe
products in the Starter Kit contain different chipsets and thus have different amounts of storage capacity for a wide range of applications. For example, content can be stored, check-in functions or certain device settings can be saved. The following products are included in this NFC Starter Kit:
- 5 x NFC sticker PET - 22 mm - NTAG213 - 180 bytes - white
- 5 x NFC sticker PET - 30 mm - NTAG215 - 540 byte - different colors - with logo
- 2 x NFC sticker PET - 30 mm - NTAG216 - 924 byte - blue
- 1 x NFC sticker PET - 30 mm - NTAG216 - 924 byte - grey
- 1 x NFC magnet PET - 30 x 30 mm - NTAG216 - 924 byte - blue
- 1 x NFC magnet PET - 30 x 30 mm - NTAG216 - 924 bytes - grey
- 2 x NFC tags epoxy - 30 mm - NTAG216 - 924 bytes - blue
- 2 x NFC tags epoxy - 30 mm - NTAG216 - 924 bytes - black
- 1 x NFC card PVC - 85 x 54 mm - NTAG216 - 924 bytes - white
- 1 x NFC protective cover - 85 x 54 mm - grey
NFC chip
The products are equipped with different chipsets of the NXP NTAG21x series... The NXP NTAG21x series impresses with the greatest possible compatibility, good performance and intelligent additional functions. Each individual chip has a unique serial number (UID) consisting of 7 bytes (alphanumeric, 14 characters). The NFC chip can be written up to 100,000 times and has a data retention of 10 years. All chips have the UID ASCII Mirror feature, which can be used to append the tag's UID to the NDEF message, as well as an integrated NFC counter that automatically increments during readout. Both features are not enabled by default. The chips are compatible with all NFC-enabled smartphones, the NFC21 tools and all ISO14443 end devices.
NFC Product | |
Available colours: | black, blue, green, grey, orange, transparent |
---|---|
Chip standards / ISO Norm: | ISO 14 443-2 A, ISO 14 443-3 A |
Dimensions: | 30 x 30 mm (W x H), 22 mm Ø, 30 mm Ø |
Material: | PET, PVC |
Storage temperature: | Min -55°C - Max +125°C |
Type: | Sticker, Magnet, Keyfob, Card |
Water resistance: | water-resistant |
NFC Chip | |
Chip: | NXP NTAG213, NXP NTAG215, NXP NTAG216 |
---|---|
Chip standards / ISO Norm: | ISO 14 443-2 A, ISO 14 443-3 A |
Frequency: | 13.56 MHz |
Memory: | 180 Byte (free: 144 Byte, NDEF: 137 Byte), 540 Byte (free: 504 Byte, NDEF: 480 Byte), 924 Byte (free: 888 Byte, NDEF: 868 Byte) |
NFC Forum Type: | NFC Forum type 2 |
Functions | |
Compatibility: | to NFC-enabled smartphones: 100% |
Data retention: | 10 years |
Data transfer rates: | 106 kbit/s |
Number of write operations: | 100.000 times |
Login
The NFC Starter Kits offer an ideal introduction to NFC technology. Not least because all products in the Starter Kits contain only original chipsets from NXP. NFC tags with NTAG chipsets are compatible with all NFC-enabled smartphones. The NFC chips are delivered without content (empty). To use the NFC chips purposefully, additional apps are required, some of which we link to below.
Android
Android smartphones with NFC require additional apps to write to NFC tags. We have compiled typical use cases in ourNFC for Android How2 collection.
iOS
NFC tags can be used in iOS with the integrated app "Shortcuts". For other use cases, we recommend an additional app, for example our freeiOS app NFC21 Tools. In ourNFC for iOS How2 collection, we have included several use cases for writing NFC tags with iOS devices.
Windows
In order to be able to use NFC tags under Windows, both suitablehardware (NFC-USB Reader / Writer)as well as suitable software. Of course you can find the suitable NFC hardware in ourshop. In ourHow2 collectionwe show how to use the NFC tags with the appropriate NFC hardware and software (e.g. ourfree software NFC21-Tools) can be used.
